Length: 27' Width: 99” OAW Height: 7’ 2” Running Gear: two 8,000lb single wheel axle with oil bath hubs Brakes: 12 ¼” x 5” electric self-charging break-away system Landing Gear: 12,000lb static drop leg jack Rear Jacks: manual pin type Wheels: 16” 8-hole steel Tires: 235/80R 16” 14-ply Frame: 6 x 4x 3/16 with 4 x 4 x 3/16 posts and 3 x 3 x 3/16 diagonal rectangular tubing Coupling System: 42,000lb capacity x 2 ½” pintle eye, adjustable in 2 ¼” increments Lights: sealed beam with waterproof wiring in nylon tubing G.V.W.R: 18,240lbs Empty Weight: 5,000lbs Payload: Approximately 13,240lbs
Capacity Quantity: four Maximum Reel Diameter: 48” Maximum Reel Width: 58” Maximum Reel WeightL 3,300lbs (each) Quantity: three Maximum Reel Diameter: 72” Maximum Reel Width: 58” Maximum Reel Weight: 4,400lbs (each) Spindle Diameter: 2 7/16” with locking collars Reel Brakes: manually actuated caliper 16” diameter disc Reel Loading: quick change type without adjusting reel brake assembly
